Ubiquiti UniFi AP AC LR - Technical Specifications

General

• Dimensions 175.7 x 175.7 x 43.2 mm (6.92 x 6.92 x 1.70")
• Weight 240 g (8.5 oz) With Mounting Kits 315 g (11.1 oz)
• Networking Interface (1) 10/100/1000 Ethernet Port
• Buttons Reset
• Antennas (1) Dual-Band Antenna, Tri-Polarity, 3 dBi
• Wi-Fi Standards 802.11 a/b/g/n/ac
• Power Method Passive Power over Ethernet (24V), (Pairs 4, 5+; 7, 8 Return)
• Power Supply 24V, 0.5A Gigabit PoE Adapter*
• Maximum Power Consumption 6.5W
• Maximum TX Power 2.4 GHz 22 dBm 5 GHz 24 dBm
• BSSID Up to Four per Radio
• Power Save Supported
• Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
• Certifications CE, FCC, IC
• Mounting Wall/Ceiling (Kits Included)
• Operating Temperature -10 to 70° C (14 to 158° F)
• Operating Humidity 5 to 95% Noncondensing
  * Only the single-pack of the UAP-AC-LR includes a PoE adapter.

Advanced Traffic Management

• VLAN 802.1Q
• Advanced QoS Per-User Rate Limiting
• Guest Traffic Isolation Supported
• WMM Voice, Video, Best Effort, and Background
• Concurrent Clients 200+

Supported Data Rates (Mbps)

• Standard Data Rates
• 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
• 802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
• 802.11b 1, 2, 5.5, 11 Mbps
• 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
